PRICE FIRM NO TAX OR FEES
SAVE on this one! Just fully cleaned, greased and looked over. Photos just taken!
– Only 257 Hours
– 6M/1500Hr FULL Warranty!
– Enclosed HEAT/AC/RADIO
– Hydraulic quick attach
– Smooth bucket Included
– 2 Speed
– Joystick controls
– 74Hp
– 8,300 lbs
Machine is TIGHT & READY TO WORK
Engine
- Model: Cat C3.3B DIT (turbo)
- Gross Power: 74.3 hp (55.4 kW)
- Net Power: 72.9 hp (54.4 kW)
- Displacement: 203 in³ (3.3 L)
- Fuel Capacity: 27.7 gal (105 L)
Weights
- Operating Weight: 8,296 lbs (3,763 kg)
Performance
- Rated Operating Capacity: 2,700 lbs (1,225 kg)
- Tipping Load: 5,400 lbs (2,455 kg)
- Breakout Force – Tilt Cylinder: 7,355 lbs (3,336 kg)
- Travel Speed (1-speed): 7.7 mph (12.4 km/h)
- Travel Speed (2-speed): 11 mph (17.7 km/h)
Hydraulics
- Standard Flow: 23 gal/min (86 L/min)
- High Flow (XPS): 32 gal/min (121 L/min)
- System Pressure (Standard Flow): 3,335 psi (23 MPa)
- System Pressure (High Flow): 4,061 psi (28 MPa)
Dimensions
- Length with Bucket: 146.2 in (3,714 mm)
- Length without Bucket: 117.9 in (2,995 mm)
- Width over Tires: 66 in (1,676 mm)
- Height to Top of Cab: 83.1 in (2,110 mm)
- Wheelbase: 49.2 in (1,249 mm)
- Ground Clearance: 8.9 in (226 mm)
- Departure Angle: 26°
- Maximum Dump Angle: 51°
- Bucket Pin Height at Maximum Lift: 124.9 in (3,172 mm)
- Reach at Maximum Lift and Dump: 30.9 in (786 mm)
- Clearance at Maximum Lift and Dump: 93.7 in (2,380 mm)
Features
- Cab: Sealed and pressurized with optional air conditioning
- Controls: Seat-mounted adjustable joystick controls
- Ride Control: Speed-sensitive system for improved load retention
- Intelligent Leveling System: Dual direction self-level, work tool return to dig, and work tool positioner
- Advanced Display: On-screen adjustments for implement response, hystat response, and creep control
