PRICE FIRM NO TAX OR FEES
This is a lightly Used machine! SAVE on this one! Just fully cleaned, Serviced, greased & looked over. Photos just taken! Delivery available!
– ONLY 654 Hours!
– Enclosed HEAT/AC/RADIO
– Hydraulic Thumb
– ZERO tail swing
– 24” bucket
– Angle blade
– 2 Speed
– 8,800 Lbs
– 25Hp
Machine is TIGHT & READY TO WORK
Engine
- Model: Kubota D1703M-DI-E4
- Type: Diesel, water-cooled, 3-cylinder
- Displacement: 100.5 cu in (1,647 cc)
- Gross Power: 24.8 HP (18.5 kW)
- Net Power: 23.9 HP (17.8 kW)
- Rated RPM: 2,200
Dimensions
- Overall Length: 15 ft 7 in (4,750 mm)
- Overall Width: 5 ft 7 in (1,700 mm)
- Overall Height: 8 ft 1 in (2,470 mm)
- Ground Clearance: 11.3 in (288 mm)
- Tail Swing Radius: 3 ft 1 in (950 mm)
Operating Weight
- With Canopy: 8,129 lbs (3,687 kg)
- With Cab: 8,499 lbs (3,856 kg)
Performance
- Max Digging Depth: 9 ft 8.9 in (2,970 mm)
- Max Dumping Height: 11 ft 1.3 in (3,385 mm)
- Max Digging Radius at Ground: 16 ft 11.2 in (5,160 mm)
- Boom Swing Angle (Left/Right): 75° / 55°
- Travel Speed (Low/High): 1.9 mph (3.0 km/h) / 2.9 mph (4.6 km/h)
- Arm Breakout Force: 4,451 lbs (2,019 kg)
- Bucket Breakout Force: 7,924 lbs (3,594 kg)
Hydraulic System
- Pump Capacity: 20.6 GPM (78.0 L/min)
- Auxiliary Hydraulic Flow: 15.8 GPM (60.0 L/min)
- System Pressure: 3,134 psi (21.6 MPa)
Fuel and Fluid Capacities
- Fuel Tank: 12.4 gal (47.0 L)
- Hydraulic Reservoir: 11.8 gal (44.6 L)
- Hydraulic System: 16.1 gal (61.0 L)
- Engine Oil: 1.4 gal (5.3 L)
- Cooling System: 1.5 gal (5.7 L)
Features
- Zero Tail Swing: Yes
- Auto Idle: Standard
- Adjustable Auxiliary Flow: Standard
- Angle Blade Option: Available
- Cab with HVAC: Available
