Heat, A/C, Backup Camera, Coupler, Third Valve, 20.5R25 Bridgestone Tires, Forks, 2.75 Yd. Bucket
Engine
- Manufacturer: John Deere
- Model: PowerTech PVS 6068
- Emission Rating: Tier 4
- Displacement: 6.8 L (414 in³)
- Rated Speed: 1,800 rpm
- Net Peak Power: 113 kW (152 hp)
- Gross Peak Torque: 713 Nm (526 lbf·ft) at 1,400 rpm
Transmission
- Type: Countershaft-type PowerShift™
- Shift Control: Electronically modulated, adaptive, load and speed dependent
Axles
- Front Differential Type: Locking
- Rear Differential Type: Open
Brakes
- Service Brake Type: Wet Disc, Hydraulic Actuation
- Parking Brake Type: Wet Multi Disc – Driveline
Tires
- Standard Size: 20.5 R25
Dimensions
- Height Over Cab: 3,330 mm (10 ft 11 in)
- Wheelbase: 2,930 mm (9 ft 7 in)
- Overall Length with Bucket: 7,370 mm (24 ft 2 in)
- Ground Clearance: 400 mm (15.7 in)
- Width Over Tires: 2,546 mm (8 ft 4 in)
- Height to Pivot Pin: 3,810 mm (12 ft 6 in)
- Reach at 45° Dump: 1,440 mm (4 ft 9 in)
- Turning Circle (Maximum): 11,800 mm (38 ft 9 in)
Capacities
- Fuel Tank: 220 L (58 gallons)
- Hydraulic Tank: 82.1 L (21.7 gallons)
- Front Axle: 16.6 L (4.375 gallons)
- Rear Axle: 18 L (4.75 gallons)
- Transmission: 21 L (5.55 gallons)
Performance
- Bucket Capacity (Heaped): 2.1 m³ (2.75 yd³)
- Bucket Capacity (Smallest): 2.1 m³ (2.75 yd³)
- Largest Bucket Capacity: 3.1 m³ (4 yd³)
- Bucket Breakout Force: 11,070 kgf (24,406 lbf)
Hydraulic System
- System Voltage: 24 V
- Alternator Output: 100 Amp
- Pump Type: Piston
- Pump Flow: 178 L/min (47 gallons/min)
- System Pressure: 250 bar (3,625 PSI)
Weights
- Operating Weight: 13,123 kg (28,931 lbs)
