PRICE FIRM NO TAX OR FEES
Just completely cleaned, Serviced, greased & looked over. Photos just Taken.
– Only 621 Hours
– Enclosed HEAT/AC/RADIO
– 12” & 36” Tooth bucket
– Zero Tail Swing
– Hydraulic Thumb
– 2 speed
– 50 Hp
– 10,900 Lbs
MACHINE IS READY TO WORK!
Engine:
- Engine Model: Bobcat D24
- Engine Type: 4-cylinder turbocharged
- Net Power: 48.5 hp (36.2 kW)
- Gross Power: 51.5 hp (38.4 kW)
- Engine Displacement: 2.4 L (146.5 cu in)
- Bore: 3.6 in (92 mm)
- Stroke: 4.4 in (112 mm)
- Rated Speed: 2,300 rpm
- Fuel Tank Capacity: 19.5 gal (73.9 L)
- Cooling System Capacity: 5.3 gal (20 L)
Dimensions:
- Operating Weight: 10,800 lbs (4,899 kg)
- Overall Length (with bucket): 15.3 ft (4,670 mm)
- Width: 6.5 ft (1,980 mm)
- Height to Top of Cab: 8.0 ft (2,435 mm)
- Ground Clearance: 11.4 in (290 mm)
- Track Length: 7.7 ft (2,350 mm)
- Track Width: 2.5 ft (760 mm)
- Tail Swing Radius: 5.4 ft (1,650 mm)
- Wheelbase: 5.4 ft (1,650 mm)
Performance:
- Max Digging Depth: 11.3 ft (3,448 mm)
- Max Reach (at Ground Level): 18.0 ft (5,500 mm)
- Max Vertical Digging Depth: 7.8 ft (2,375 mm)
- Max Dump Height: 11.7 ft (3,550 mm)
- Bucket Breakout Force: 7,800 lbf (34.7 kN)
- Arm Breakout Force: 5,430 lbf (24.2 kN)
- Max Reach (at Full Height): 14.3 ft (4,375 mm)
Hydraulic System:
- Hydraulic Pump Flow: 23.8 gal/min (90 L/min)
- Auxiliary Hydraulic Flow: 15.9 gal/min (60 L/min)
- Auxiliary Hydraulic Pressure: 3,300 psi (22,800 kPa)
- Max Operating Pressure: 3,300 psi (22,800 kPa)
- Hydraulic Tank Capacity: 8.0 gal (30 L)
Undercarriage:
- Track Gauge: 5.5 ft (1,690 mm)
- Track Type: Rubber or steel (optional)
- Undercarriage Design: Standard or long-arm (optional)
Cab Features:
- ROPS: ISO 3471:2008
- FOPS: ISO 3449:2005 Level II
- Operator Station: Spacious, ergonomically designed with climate control (AC and heat optional), adjustable seat, and joystick controls
- Heater and Air Conditioning: Optional
Brakes and Safety:
- Brakes: Hydraulic wet disc brakes
- Parking Brake: Automatic engagement
- Safety Features:
- ISO standard rollover protection (ROPS)
- Falling object protection (FOPS)
- Seatbelt interlock
- Travel alarm
- Back-up alarm
Operating Specifications:
- Max Travel Speed: 5.4 mph (8.7 km/h)
- Max Arm Force (Lift): 4,435 lbf (19.7 kN)
- Max Arm Force (Dig): 7,590 lbf (33.7 kN)
- Max Traction Force: 7,565 lbf (33.6 kN)
Electrical System:
- Alternator: 90A
- Battery: 12V, 650 CCA
- Lights: LED front and rear lights
- Horn: Standard
Weights and Capacities:
- Operating Weight: 10,800 lbs (4,899 kg)
- Bucket Capacity: 0.42 – 0.64 yd³ (0.32 – 0.49 m³)
- Fuel Tank Capacity: 19.5 gal (73.9 L)
- Hydraulic Tank Capacity: 8.0 gal (30 L)
Optional Attachments:
- Buckets: General purpose, heavy-duty, or grading buckets (various sizes)
- Augers, hydraulic breakers, and other attachments available
