Engine
- Model: Kubota D1703M-DI-E4
- Gross Power: 24.8 hp (18.5 kW)
- Net Power: 23.2 hp (17.3 kW)
- Displacement: 100.5 in³ (1,647 cc)
- Fuel Capacity: 12.4 gal (46.9 L)
Weights
- Operating Weight: 7,616 lbs (3,454 kg)
Performance
- Maximum Digging Depth: 10 ft 6 in (3.2 m)
- Maximum Reach at Ground Level: 16 ft 10 in (5.1 m)
- Bucket Digging Force: 8,138 lbf (3,694 kgf)
- Arm Digging Force: 3,867 lbf (1,756 kgf)
- Travel Speed (Low): 1.9 mph (3.0 km/h)
- Travel Speed (High): 2.9 mph (4.6 km/h)
Hydraulics
- Pump Capacity: 10.5 gal/min × 2 + 5.5 gal/min × 1 (39.6 L/min × 2 + 20.9 L/min × 1)
- Auxiliary Hydraulic Flow: 15.8 gal/min (60 L/min)
Dimensions
- Overall Length: 15 ft 6 in (4.73 m)
- Overall Width: 5 ft 1 in (1.55 m)
- Overall Height: 8 ft 1 in (2.48 m)
- Ground Clearance: 11.4 in (290 mm)
Features
- ROPS/FOPS: Canopy or Cab
- Tracks: Rubber or Steel
- Hydraulic System: Load Sensing Hydraulic System
- Auxiliary Hydraulics: Standard
- Angle Blade: Optional
