Heat, A/C, Radio, Backup Camera, Hydraulic Coupler, 28″ Pads, 36″ Bucket
Engine
- Model: Komatsu SAA4D107E-3
- Net Horsepower: 121 HP @ 2,100 rpm
- Displacement: 272 in³ (4.46 L)
- Emission Certification: EPA Tier 4 Final
Operating Weight
- Standard Counterweight: 38,720 – 41,597 lbs (17,570 – 18,870 kg)
- Heavy Counterweight: 42,015 – 42,895 lbs (19,060 – 19,460 kg)
Performance
- Maximum Digging Depth: 20 ft 6 in (6,250 mm)
- Maximum Reach at Ground Level: 28 ft 10 in (8,800 mm)
- Bucket Capacity: 0.48 – 1.24 yd³ (0.37 – 0.95 m³)
- Bucket Digging Force (ISO): 27,651 lbs (12,500 kg)
- Arm Digging Force (ISO): 19,401 lbs (8,800 kg)
Hydraulics
- Main Pumps: 2 variable capacity piston pumps
- Maximum Flow: 78.7 gal/min (298 L/min)
- Relief Valve Setting: 5,450 psi (37.6 MPa)
Dimensions
- Overall Length: 28 ft 6 in (8,690 mm)
- Overall Width: 8 ft 2 in (2,490 mm)
- Overall Height: 9 ft 11 in (3,020 mm)
- Ground Clearance: 1 ft 5 in (450 mm)
Undercarriage
- Track Shoe Width: 24 – 31.5 in (600 – 800 mm)
- Number of Shoes (each side): 44
- Number of Track Rollers (each side): 7
- Number of Carrier Rollers (each side): 2
Capacities
- Fuel Tank: 79.25 gal (300 L)
- DEF Tank: 7.81 gal (29.6 L)
- Hydraulic Tank: 32.0 gal (121 L)
- Engine Oil: 4.8 gal (18 L)
- Cooling System: 7.21 gal (27.3 L)
