Series II, 6 cyl John Deere turbo diesel, cab with heat, A/C, stereo, autoshift, keyless start, 20.5R25 radial rubber, GP bucket with BOCE, meter reads 14244 hours, S/N 1DW544KZAHF684860
Engine
- Model: John Deere PowerTech PVS 6068
- Net Power: 163 hp (121.6 kW)
- Displacement: 415 in³ (6.8 L)
- Rated Speed: 1,800 rpm
- Emission Level: Tier 4
Weights
- Operating Weight: 29,139 lbs (13,217 kg)
Performance
- Bucket Capacity: 3.0–4.5 yd³ (2.3–3.4 m³)
- Bucket Breakout Force: 22,300 lbs (10,115 kgf)
- Static Tipping Load (Full Turn): 21,246 lbs (9,637 kg)
- Hydraulic Pump Flow: 50 gal/min (189 L/min)
- System Pressure: 3,650 psi (25.2 MPa)
Dimensions
- Length with Bucket on Ground: 24 ft 5 in (7.44 m)
- Width over Tires: 8 ft 4 in (2.54 m)
- Height to Top of Cab: 10 ft 7.5 in (3.24 m)
- Wheelbase: 9 ft 7.5 in (2.93 m)
- Ground Clearance: 1 ft 3.75 in (0.40 m)
- Hinge Pin Height at Max Lift: 12 ft 6.5 in (3.82 m)
- Dump Clearance at Max Lift: 9 ft 1 in (2.77 m)
- Reach at Max Lift and Dump: 4 ft 9.5 in (1.46 m)
- Turning Radius: 20 ft 1.5 in (6.13 m)
Transmission
- Type: Powershift
- Number of Forward Gears: 5
- Number of Reverse Gears: 3
- Max Speed – Forward: 22.2 mph (35.7 km/h)
- Max Speed – Reverse: 15 mph (24.1 km/h)
Hydraulics
- Relief Valve Setting: 3,650 psi (25.2 MPa)
- Pump Type: Variable displacement, axial piston
- Raise Time: 5.8 seconds
- Dump Time: 1.2 seconds
- Lower Time: 3.2 seconds
Capacities
- Fuel Tank: 78.8 gal (298 L)
- Hydraulic Tank: 31.4 gal (119 L)
- Transmission: 5.7 gal (21.6 L)
- Front Axle/Diff: 4.8 gal (18.2 L)
- Rear Axle/Diff: 4.8 gal (18.2 L)
Tires
- Standard Size: 20.5 R25
