– Heat
– A/C
– Backup Camera
– Hydraulic Coupler
– Hydraulic Thumb
– 42″ Bucket
Engine
- Model: JCB EcoMAX T4i/Stage IIIB
- Net Power: 172 hp (128 kW) at 2,000 rpm
- Displacement: 317 in³ (5.2 L)
- Fuel Capacity: 91 gal (344 L)
Weights
- Operating Weight: 48,290 lbs (21,904 kg)
Performance
- Maximum Digging Depth: 22 ft (6.7 m)
- Maximum Reach at Ground Level: 32 ft (9.8 m)
- Bucket Capacity: 1.5 yd³ (1.1 m³)
- Maximum Travel Speed: 3.4 mph (5.5 km/h)
- Drawbar Pull: 43,144 lbs (19,570 kg)
Hydraulics
- Main Pumps: 2 variable displacement axial piston type
- Maximum Flow: 2 x 214 L/min (2 x 47 UK GPM)
- Relief Valve Settings: 4,975 psi (343 bar)
- Hydraulic System Fluid Capacity: 53 gal (201 L)
Dimensions
- Transport Length: 31 ft (9.4 m)
- Transport Width: 10 ft (3.0 m)
- Transport Height: 10 ft (3.0 m)
- Ground Clearance: 1.58 ft (0.48 m)
- Tail Swing Radius: 9.25 ft (2.8 m)
