Cab,A/C, meter reads 2852 hours, 6-way blade, grade control.
Engine
- Model: Cat C4.4 ACERT
- Gross Power: 104 hp (78 kW)
- Net Power: 104 hp (78 kW)
- Displacement: 269 in³ (4.4 L)
- Number of Cylinders: 4
Weights
- Operating Weight: 20,992 lbs (9,522 kg)
Performance
- Maximum Speed – Forward: 5.6 mph (9 km/h)
- Maximum Speed – Reverse: 6.2 mph (10 km/h)
Hydraulics
- Pump Flow Capacity: 17.7 gal/min (67 L/min)
- Relief Valve Pressure: 2,988 psi (20,600 kPa)
Dimensions
- Length with Blade: 169.1 in (4,297 mm)
- Width Over Tracks: 94.9 in (2,411 mm)
- Height to Top of Cab: 109 in (2,769 mm)
- Length without Blade: 128.5 in (3,264 mm)
Undercarriage
- Standard Shoe Size: 26 in (660 mm)
- Number of Shoes per Side: 40
- Number of Track Rollers per Side: 7
- Ground Contact Area: 4,726 in² (3.05 m²)
- Ground Pressure: 4.5 psi (31.1 kPa)
Blade
- Width: 126.7 in (3,219 mm)
- Height: 39.8 in (1,011 mm)
- Capacity: 3.1 yd³ (2.37 m³)
- Blade Angle (Both Directions): 58 degrees
Service Refill Capacities
- Fuel Tank: 51.5 gal (195 L)
- Cooling System: 3 gal (11 L)
- Engine Oil: 2.6 gal (10 L)
- Hydraulic Fluid: 2.6 gal (10 L)
- Powertrain Fluid: 6 gal (23 L)
- Final Drives (each): 15.7 gal (59 L)
