Caterpillar 313FL Excavator -2 Speed, Back Up Camera, Auxiliary Hydraulics, Hydraulic Coupler, 4ft Front Bucket, 27.5 Steel Tracks, Operating Weight: 33,080lb
Specifications
Engine
- Model: Cat® C4.4 ACERT™
- Net Power: 92 hp (69 kW)
- Gross Power: 100 hp (74 kW)
- Displacement: 269 in³ (4.4 L)
Weights
- Minimum Operating Weight: 29,770 lbs (13,500 kg)
- Maximum Operating Weight: 33,080 lbs (15,000 kg)
Performance
- Maximum Travel Speed: 3.7 mph (6 km/h)
- Maximum Drawbar Pull: 25,628 lbf (114 kN)
- Swing Speed: 10.9 rpm
- Swing Torque: 22,791 lbf·ft (30,900 N·m)
Hydraulics
- Main System Maximum Flow: 67 gal/min (254 L/min)
- Maximum Pressure – Equipment: 4,424 psi (30,500 kPa)
- Maximum Pressure – Swing: 3,336 psi (23,000 kPa)
- Maximum Pressure – Travel: 5,076 psi (35,000 kPa)
Service Refill Capacities
- Fuel Tank Capacity: 58.9 gal (223 L)
- Cooling System: 5.9 gal (22 L)
- Engine Oil (with filter): 3.6 gal (13.5 L)
- Hydraulic System (including tank): 43.4 gal (164 L)
- Hydraulic Tank: 24 gal (90.6 L)
- Final Drive (each): 0.8 gal (3 L)
- Swing Drive: 0.7 gal (3 L)
Dimensions
- Shipping Height: 9.75 ft (2.97 m)
- Shipping Length: 25.17 ft (7.67 m)
- Tail Swing Radius: 7.08 ft (2.16 m)
- Ground Clearance: 1.42 ft (0.43 m)
- Track Length: 12.33 ft (3.76 m)
- Track Gauge: 6.5 ft (1.99 m)
- Transport Width (700 mm shoes): 8.83 ft (2.69 m)
Working Ranges (with 4.65 m boom and 3.0 m stick)
- Maximum Digging Depth: 19.9 ft (6.06 m)
- Maximum Reach at Ground Level: 28.3 ft (8.63 m)
- Maximum Cutting Height: 28.6 ft (8.72 m)
- Maximum Loading Height: 20.8 ft (6.34 m)
- Minimum Loading Height: 5 ft (1.52 m)
- Maximum Vertical Wall Digging Depth: 17.1 ft (5.21 m)
