CHA, 4WD, 4 Speed Powershift Trans, 2200 Hours, 127 HP, AM/FM/WB Radio, Air Seat, Pilot Controls w/Pattern Changer, 4 In 1 96″ Bucket, Auxiliary Hyd, Extendahoe w/16″ Bucket, 15-16.5 Front Tires R-@ 40% L-@ 50%, 21L-24 Rear Tires R-@ 65% L-@ 85%
Engine
- Model: Cat C4.4 ACERT™
- Net Power (SAE J1349): 127 hp (95 kW)
- Gross Power (ISO 14396): 142 hp (106 kW)
- Displacement: 268 in³ (4.4 L)
Weights
- Operating Weight (Maximum): 27,115 lbs (12,300 kg)
- Operating Weight (Nominal): 24,141 lbs (10,950 kg)
Performance
- Backhoe Dig Depth (Standard Stick): 17 ft 3 in (5.26 m)
- Backhoe Dig Depth (Extendable Stick Extended): 21 ft 4 in (6.5 m)
- Loader Lift Capacity at Full Height (Single Tilt): 7,871 lbs (3,570 kg)
- Bucket Breakout Force (Single Tilt): 11,375 lbf (50,600 N)
- Travel Speed (4th Gear Forward): 25 mph (40 km/h)
Hydraulics
- System Type: Load-sensing, closed center
- Pump Type: Variable-flow, axial piston
- Pump Capacity at 2,200 rpm: 50 gal/min (189 L/min)
- System Pressure – Backhoe: 3,800 psi (26,200 kPa)
- System Pressure – Loader: 3,550 psi (24,500 kPa)
Dimensions
- Transport Length: 24 ft 6 in (7.47 m)
- Transport Width: 7 ft 11 in (2.41 m)
- Transport Height: 12 ft 1 in (3.68 m)
- Wheelbase (AWD): 7 ft 3 in (2.2 m)
- Ground Clearance: 1 ft 2 in (0.37 m)
