Heat, A/C, Radio, Backup Camera, Hydraulic Elevated Cab, Robotec Grapple, 10’2″ Stick
Engine
- Model: Volvo D6H
- Gross Power: 154 hp (115 kW)
- Net Power: 150 hp (112 kW)
- Displacement: 347.9 in³ (5.7 L)
- Number of Cylinders: 6
Performance
- Operating Weight: 37,715 lbs (17,107 kg)
- Maximum Digging Depth: 16 ft 11 in (5.15 m)
- Maximum Digging Reach: 28 ft 3 in (8.6 m)
- Maximum Dumping Height: 19 ft 6 in (5.95 m)
- Tail Swing Radius: 7 ft 0.75 in (2.16 m)
- Travel Speed (On Road): 22 mph (35 km/h)
- Travel Speed (Off Road): 5 mph (8 km/h)
Hydraulics
- Main Pump Type: Low Noise Axial Piston Pump
- Maximum Flow: 67.7 gal/min (256 L/min)
- Implement Pressure: 4,930 psi (34 MPa)
- Travel Circuit Pressure: 5,440 psi (37.5 MPa)
- Pilot Circuit Pressure: 490 psi (3.4 MPa)
Dimensions
- Overall Length: 27 ft 0.75 in (8.25 m)
- Overall Width: 8 ft 11.25 in (2.72 m)
- Overall Height (to top of cab): 10 ft 3.75 in (3.14 m)
- Wheelbase: 8 ft 6.5 in (2.6 m)
- Ground Clearance: 1 ft 2.25 in (0.36 m)
Capacities
- Fuel Tank: 66.1 gal (250 L)
- Hydraulic Tank (Total System): 68.7 gal (260 L)
- Hydraulic Tank: 32.5 gal (123 L)
- Engine Oil: 6.7 gal (25.4 L)
- Engine Coolant: 8.8 gal (33.3 L)
