Cab,A/C, meter reads 6978 hours, CAT Infusion Coupler, CAT FORKS, GP bucket, backup camera
Engine
- Model: Cat C7.1 ACERT
- Gross Power: 154 hp (115 kW)
- Net Power: 152 hp (113 kW)
- Displacement: 402 in³ (6.6 L)
- Number of Cylinders: 6
Weights
- Operating Weight: 30,479 lbs (13,825 kg)
Performance
- Bucket Capacities: 2.1–5.0 m³ (2.7–6.5 yd³)
- Static Tipping Load (Full Turn): 18,444 lbs (8,366 kg)
- Breakout Force: 28,551 lbs (12,950 kg)
- Hydraulic Cycle Time (Raise): 5.1 seconds
- Hydraulic Cycle Time (Dump): 1.5 seconds
- Hydraulic Cycle Time (Lower, Empty, Float Down): 2.7 seconds
- Hydraulic Cycle Time (Total): 9.3 seconds
Hydraulics
- Pump Flow Capacity: 50 gal/min (189 L/min)
- Relief Valve Setting: 3,626 psi (25,000 kPa)
Dimensions
- Overall Length: 24 ft 8 in (7.53 m)
- Overall Width (over tires): 8 ft 4 in (2.54 m)
- Height to Top of ROPS/FOPS: 10 ft 11 in (3.34 m)
- Wheelbase: 9 ft 10 in (3.00 m)
- Ground Clearance: 1 ft 3 in (0.397 m)
- Dump Clearance at Full Lift and 45° Dump Angle: 9 ft 3 in (2.82 m)
- Reach at Full Lift and 45° Dump: 3 ft 5 in (1.06 m)
Transmission
- Number of Forward Gears: 4
- Number of Reverse Gears: 4
- Max Speed – Forward: 25 mph (40 km/h)
- Max Speed – Reverse: 25 mph (40 km/h)
Service Refill Capacities
- Fuel Tank: 51.5 gal (195 L)
- Cooling System: 8.5 gal (32 L)
- Hydraulic System (including tank): 43.6 gal (165 L)
- Hydraulic Tank: 23.8 gal (90 L)
- Engine Crankcase: 5.3 gal (20 L)
- Transmission: 2.2 gal (8 L)
- Front Axle/Diff: 6.9 gal (26 L)
- Rear Axle/Diff: 6.9 gal (26 L)
