Caterpillar 3412 V12 turbo diesel, cab with heat, A/C, 61 ton capacity, 24.00R35 radial rubber, meter reads 34784 hours, S/N 63W04430
Engine
- Model: Caterpillar 3412
- Net Power: 650 hp (485 kW)
- Gross Power: 683 hp (509 kW)
- Displacement: 1,648 in³ (27 L)
- Aspiration: Turbocharged and aftercooled
Weights
- Empty Weight: 86,853 lbs (39,396 kg)
- Loaded Weight: 204,003 lbs (92,534 kg)
Performance
- Rated Payload: 119,000 lbs (53,977 kg)
- Top Speed: 35.7 mph (57.3 km/h)
- Transmission: 7 forward gears, 1 reverse gear
Dimensions
- Overall Length: 30.42 ft (9,270 mm)
- Overall Width: 15.42 ft (4,700 mm)
- Overall Height: 13.88 ft (4,230 mm)
- Wheelbase: 13.75 ft (4,190 mm)
- Ground Clearance: 1.94 ft (591 mm)
Dump Body
- Load Capacity – Struck: 34.01 yd³ (26 m³)
- Load Capacity – Heaped: 44.61 yd³ (34.1 m³)
- Dump Angle: 54.5 degrees
- Raise Time: 11.4 seconds
- Lower Time: 14.2 seconds
Operational Capacities
- Fuel Capacity: 185 gal (700 L)
- Cooling System Fluid Capacity: 39.9 gal (151 L)
- Engine Oil Capacity: 18 gal (68 L)
- Differential and Final Drive Fluid Capacity: 41 gal (155 L)
- Steering System Fluid Capacity: 21.4 gal (81 L)
Tires
- Size: 21.00-35 32PR (E-3)
